connecting . two . worlds
As form factors continue to shrink, while at the same time ever increasing complex electronics are still
expected to fit seamlessly, ECAD/MCAD Collaboration must be a natural part of your product design cycle.
Modern designs require functionality that spans multiple design disciplines. This requires close communication between electrical
and mechanical engineers from each team. Designers are no longer bound by a single domain. Many products result from collaboration with teams
that work across multiple countries and continents, which presents a challenge when communicating between the different designers and
engineers in a electro-mechanical system.
Many product designs are conceived in the MCAD domain and historically design reviews take place late in the overall design cycle, therefore
causing maximum disruption and forcing non optimal trade-offs and effort to get to market on time. The prostep ECAD/MCAD Collaboration
standard supports the instant communication of design intent and incremental changes.
IDX supports the continued real time synchronization of the ECAD and MCAD designs. The tighter integration will lowers risk and improves time
to market.
Most issues with collaboration can be traced back to the limitations of the format that was used during the exchange. To date, the Intermediate
Data Format (IDF) and Drawing eXchange Format (DXF) have been widely-used to exchange PCB data between mechanical and electrical designs.
IDF was initially developed and released in 1992 and was updated until 1998. DXF, on the other hand, was released in 1982. For older designs,
IDF and DXF provided a powerful mechanism to collaborate between electrical and mechanical domains, however with the evolution of the workforce
and ever-changing product complexity and scale of the products we design, these static formats can end up hindering the design process instead
of facilitating it.
With the introduction of the ProSTEPiViP Incremental Data Exchange (IDX) communication protocol, designers are now able to fully sychronize
their data between both ECAD and MCAD and more effectively collaborate on criticle design items between domains, ensuring that the design
intent is interpreted correctly. This allows designers to collaborate and identify issues much more easily throughout the design process,
which in turn enables more robust designs that get out to market faster.
The aim of the ECAD/MCAD Collaboration Implementor Forum (IF) is not only to develop a standard for the exchange of ECAD and MCAD data,
but also simplify the implementation for vendors. For this reason, in addition to adding new functionality to IDX schema we’ve also
significantly simplified the way items are described in the format. Information and examples of how to describe items using the new
simplified standard format are available in the “Implementation Guidelines”. These Guidelines and the Recommendation documents are available
for free from the prostep ivip Media Library.
| Design Object | IDX | IDF |
|---|---|---|
| Incremental Changes | ||
| Accept / Reject Changes | ||
| Comments on Changes | ||
| Change History Tracking | ||
| Board Outline | ||
| Stackup Structure | ||
| Multiple Stackups(Flex/Flex-rigid) | ||
| Board Bend Areas | ||
| Board Cutouts(Contours) | ||
| Board Cavities | ||
| Components | ||
| Holes | ||
| Obstructs/Keep-out | ||
| Room | ||
| Traces | ||
| Pads | ||
| Copper Shapes | ||
| Pin 1 Location | ||
| Object Ownership |
In this Project Group prostep ivip
is working together with different
partners from the industries:
| Company | Product | Integration Tool | Additional Information |
|---|---|---|---|
| CADCAM Group | Catia V5 | MECODES | Link |
| CADCAM Group | 3DEXPERIENCE Catia | MECODES | Link |
| Cadence Design Systems | Allegro X | MCAD Collaboration | Link |
| Cadence Design Systems | OrCAD X | MCAD Collaboration | Link |
| Dassault Systèmes | SolidWorks | CircuitWorks | Link |
| Dassault Systèmes | 3DEXPERIENCE Catia | Circuit Board Design | Link |
| PTC | Creo Parametric | ECAD-MCAD Collaboration Extension | Link |
| PTC | Onshape | PCB Studio | Link |
| Siemens | Xpedition | MCAD Collaborator | Link |
| Siemens | PADS Professonal | MCAD Collaborator | Link |
| Siemens | NX | PCB Exchange | Link |
| Siemens | Solid Edge | ECAD Collaborator | Link |
| Zuken | Design Force | EMD Collaborator | Link |
